Firestop Clash Management

The FCM (Firestop Clash Management) plugin for Autodesk Revit® uses clash detection to find locations where penetrants meet fire-rated barriers and automatically selects the appropriate firestop systems. It removes the complexity of designing firestop systems and ensures that when it comes time for construction, the systems selected provide the fastest installation and best installed cost.

Firestop 101

The learner will understand the basic principles of how passive fire protection factors into the overall life safety and code compliance of buildings and why firestopping is used today. They will learn how to read the UL directory and locate appropriate tested systems for the application type. They will also gain an understanding on how to identify where firestopping should be used and if an alternate solution may be necessary as well as how to properly install the correct firestop product. (AIA 2 LUs|HSW; BICSI 2 CECs).

Watch Webinar
Step 1
Clash Detection

Clash Detection

Scan the Revit® model to find clash points where firestopping is required.

Step 2
Clash Detection

Clash Detection

Scan the Revit® model to find clash points where firestopping is required.

Step 3
Clash Detection

Clash Detection

Scan the Revit® model to find clash points where firestopping is required.

download button strucsoft

Plugin Features

  • Clash detection finds locations where penetrants intersect rated barriers
  • Best UL Certified firestop system for each condition selected and inserted into model at clash location
  • Openings are designed based on optimal UL System design parameters
  • Connects automatically to STI’s System Search to ensure latest system revision is selected
  • Automatically generate an openings report for construction coordination

Compatible with Autodesk Revit® 2018 – 2021
